CAPTCHA Handling in Mobile Apps with Appium

Mobile apps frequently embed CAPTCHAs in WebViews — reCAPTCHA, Turnstile, or hCaptcha rendered inside a native app. Appium can switch into these WebViews, extract sitekeys, and inject solved tokens from CaptchaAI.

How CAPTCHAs appear in mobile apps

Pattern	Description	Approach
WebView CAPTCHA	reCAPTCHA/Turnstile in an embedded WebView	Switch to WebView context, extract sitekey
Browser redirect	App opens system browser for auth	Use Appium to read browser URL, solve externally
Native CAPTCHA	Custom image CAPTCHA rendered natively	Screenshot and use Image/OCR solver

Most mobile CAPTCHAs are WebView-based — the same reCAPTCHA used on the web.

Setup: Appium with WebView debugging

Prerequisites

# Android: Enable WebView debugging in the app
# (Developers must set WebView.setWebContentsDebuggingEnabled(true))
# Or use a debug build of the app

# Install Appium
npm install -g appium
appium driver install uiautomator2  # Android
appium driver install xcuitest      # iOS

Appium capabilities

# Python
from appium import webdriver
from appium.options.android import UiAutomator2Options

options = UiAutomator2Options()
options.platform_name = "Android"
options.device_name = "emulator-5554"
options.app = "/path/to/app.apk"
options.auto_grant_permissions = True

driver = webdriver.Remote("http://localhost:4723", options=options)

Step 1: Find and switch to the WebView

import time

# Wait for WebView to load
time.sleep(5)

# List available contexts
contexts = driver.contexts
print(f"Contexts: {contexts}")
# ['NATIVE_APP', 'WEBVIEW_com.example.app']

# Switch to WebView
webview_context = [c for c in contexts if "WEBVIEW" in c]
if webview_context:
    driver.switch_to.context(webview_context[0])
    print(f"Switched to: {webview_context[0]}")

JavaScript (WebdriverIO)

const { remote } = require('webdriverio');

const driver = await remote({
  capabilities: {
    platformName: 'Android',
    'appium:deviceName': 'emulator-5554',
    'appium:app': '/path/to/app.apk',
    'appium:automationName': 'UiAutomator2',
  },
});

// Wait and switch to WebView
await driver.pause(5000);
const contexts = await driver.getContexts();
const webview = contexts.find(c => c.includes('WEBVIEW'));
if (webview) {
  await driver.switchContext(webview);
}

Step 2: Extract the sitekey

Once in the WebView context, you have full DOM access:

# In WebView context — same as browser automation
sitekey = driver.execute_script("""
    // reCAPTCHA
    const recaptcha = document.querySelector('.g-recaptcha');
    if (recaptcha) return { type: 'recaptcha', sitekey: recaptcha.getAttribute('data-sitekey') };

    // Turnstile
    const turnstile = document.querySelector('.cf-turnstile');
    if (turnstile) return { type: 'turnstile', sitekey: turnstile.getAttribute('data-sitekey') };

    // hCaptcha
    const hcaptcha = document.querySelector('.h-captcha');
    if (hcaptcha) return { type: 'hcaptcha', sitekey: hcaptcha.getAttribute('data-sitekey') };

    return null;
""")

page_url = driver.current_url
print(f"Type: {sitekey['type']}, Key: {sitekey['sitekey']}, URL: {page_url}")

Step 3: Solve with CaptchaAI

import requests

API_KEY = "YOUR_API_KEY"

method_map = {
    "recaptcha": "userrecaptcha",
    "turnstile": "turnstile",
    "hcaptcha": "hcaptcha",
}

# Build submit params
submit_data = {
    "key": API_KEY,
    "method": method_map[sitekey["type"]],
    "pageurl": page_url,
    "json": "1",
}

# Type-specific key parameter
if sitekey["type"] == "recaptcha":
    submit_data["googlekey"] = sitekey["sitekey"]
else:
    submit_data["sitekey"] = sitekey["sitekey"]

resp = requests.post("https://ocr.captchaai.com/in.php", data=submit_data).json()
task_id = resp["request"]

# Poll
for _ in range(24):
    time.sleep(5)
    result = requests.get("https://ocr.captchaai.com/res.php", params={
        "key": API_KEY, "action": "get", "id": task_id, "json": "1"
    }).json()

    if result["status"] == 1:
        token = result["request"]
        print(f"Token: {token[:50]}...")
        break
    if result["request"] != "CAPCHA_NOT_READY":
        raise Exception(f"Error: {result['request']}")

Step 4: Inject the token

# Still in WebView context
token_field_map = {
    "recaptcha": "g-recaptcha-response",
    "turnstile": "cf-turnstile-response",
    "hcaptcha": "h-captcha-response",
}

field_name = token_field_map[sitekey["type"]]

driver.execute_script(f"""
    // Set the hidden input
    const input = document.querySelector('textarea[name="{field_name}"], input[name="{field_name}"]');
    if (input) {{
        input.value = arguments[0];
        input.style.display = 'block';
    }}

    // Trigger callback if exists
    const widget = document.querySelector('.g-recaptcha, .cf-turnstile, .h-captcha');
    const callback = widget?.getAttribute('data-callback');
    if (callback && typeof window[callback] === 'function') {{
        window[callback](arguments[0]);
    }}
""", token)

# Submit the form
driver.execute_script("document.querySelector('form').submit()")

# Switch back to native context
driver.switch_to.context("NATIVE_APP")

Handling native image CAPTCHAs

If the CAPTCHA is rendered natively (not in a WebView), screenshot and use Image/OCR:

import base64

# Switch to native context
driver.switch_to.context("NATIVE_APP")

# Find and screenshot the CAPTCHA element
captcha_element = driver.find_element("id", "captcha_image")
screenshot_b64 = captcha_element.screenshot_as_base64

# Submit to CaptchaAI as image
resp = requests.post("https://ocr.captchaai.com/in.php", data={
    "key": API_KEY,
    "method": "base64",
    "body": screenshot_b64,
    "json": "1",
}).json()

task_id = resp["request"]

# Poll and get text answer
for _ in range(20):
    time.sleep(5)
    result = requests.get("https://ocr.captchaai.com/res.php", params={
        "key": API_KEY, "action": "get", "id": task_id, "json": "1"
    }).json()
    if result["status"] == 1:
        answer = result["request"]
        break

# Type the answer into the input field
captcha_input = driver.find_element("id", "captcha_input")
captcha_input.send_keys(answer)

Troubleshooting

Problem	Cause	Fix
No WEBVIEW context	WebView debugging not enabled	Use a debug build or set `setWebContentsDebuggingEnabled(true)`
Can't find sitekey	CAPTCHA loaded dynamically	Add wait before extraction; use MutationObserver
Token injection fails	Wrong field name	Check the CAPTCHA type and corresponding input name
Context switch fails	Multiple WebViews	List all contexts and select the correct one

FAQ

Does this work on iOS?

Yes. Use the xcuitest driver. iOS WebViews are automatically debuggable in simulator and development-signed apps.

What if the app uses a custom browser?

If the app opens Chrome Custom Tabs or SFSafariViewController, Appium can't access the content. Use a proxy to intercept the CAPTCHA parameters instead.
